Description
Application : Wall Board,Ceilings,Partitions,Panelings,Claddings,Carpentry.
Features : Water Resistant, Fire Resistant, Antibacterial, Water Resistant.
Density(kg/m3) : 850
Thickness : 6mm, 8mm, 10mm and 12mm
Size of sheet :1.22m x 2.44m
Mechanical and Physical Characteristics:
Apparent Density (Dry) Kg/m IS 14862:2OOO >1200
Modulus of Rupture (EMC) MPa IS 14862.2OOO 14- Parallel, 8 – Perpendicular
Impact Strength J/m? – >2100
Compressive Strength MPa ASTM D1037 >30
Tensile Strength MPa ASTM D1037 20 – Parallel, 18 – Perpendicular
Screw Withdrawal Strength Ν |S:2380 Part XIV >1300
Moisture Content (EMC) % – <12
1) Apparent Density (Dry) Kg/m IS 14862:2OOO >1200
2) Modulus of Rupture (EMC) MPa IS 14862.2OOO 14- Parallel, 8 – Perpendicular
3) Impact Strength J/m? – >2100
4) Compressive Strength MPa ASTM D1037 >30
5) Tensile Strength MPa ASTM D1037 20 – Parallel, 18 – Perpendicular
6) Screw Withdrawal Strength Ν |S:2380 Part XIV >1300
7) Moisture Content (EMC) % – <12
Biological – – No fungus growth.
| Sound Insulation | Heat Insulation | Fire Protection | |||
| Acoustic Insulation CB |IS:9901: Part 3:1981 29 | Thermal Conductivity W/m-K ASTM C177 and ISO 83O2 0.18 | Combustibility – BS 476:Part 4:1970 Non-Combustible |
TYPES OF BUILDINGS PERFORMANCE FEATURES PLACES TO BE USed :
Hospitals, Schools, Railway Stations,high Impact Strength Partitions,Software Parks, Theatres, Commercial Complexes, Warehouses,High Flexural Strength AC Ventilation Ducts,Water Resistance Offices, Bus Terminus, Petrol Bunks.
